224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯生产发电用热车机燃料生活性好: 一流的燃料把握体统，特有的STC、ESTC 分级制度把握体统，唯一性方案的缸筒最上层挥发室，直流电噴射燃料，充足雾化吸入，挥发充足。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电量用打着机瞬态能优质: 完满的打着机总体定制，能默契配合康明斯鲜明的EFC系统软件，有效控制精确高，异常时快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯来发电用热车机升额定功率高: 局部的设计紧凑型轿车.外貌安排合理化，运作平静。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷外形 QSNT. QSK19. QSK38. QSK50必须中国国非方向三是环节及美国Tier2. Tier 3产生法律必须。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零维修工具都有机会得到性好， 发起机加载及维保日常护理社区便利店，成本可控低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

耗油率范围内 Power Range   224-310KW型号规格 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外观长度 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净性能 Dry Weight   940kg

224-310KW康明斯并网发电用热车机的优点和缺点：密度小， 解压缩比较高， 喷淋喷嘴的空气微波加热，最易加载，中国移动车截交流电源的优选。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

发起机材质	经常用功效(kW)Prime Power	预备输出功率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
